| System | Windows
Window door
Ventilation systeme
|
| Material | Alumínium |
| Energy | Highly thermally insulated (1,0 ≤ Uf ≤ 1,3) |
| Types | Turn windows
Combined pivoting hopper window
Toplights
Fixed glazing
Double vent window
PASK-window door
Renovation window
Supply air
|
| Security | Burglar resistant RC2
Burglar resistant RC3
Protection class SK1
Protection class SK2
Protection class SK3
Protection class SK4
Flue
Supply air elements/slipstream
|
| Features | Schüco TipTronic
Motorisable
Schüco WindowControlSystem WCS
Controllable
Comfort control
Radio system
Decentralized ventilation
Raised sound insulation
Fall protection
|
| Control | Manuell switchable
Electric switchable
VOC control
CO2 control
Wet control
Wind control
Approximation control
Switch rail control
Magnetic switch control
|
| Design | Standard
Block system
Multi Countour
|
| Surface | Alu crude (refinementable) |
| Sound insulation | increased sound insulation 38 - 45 dB
increased sound insulation more than 45 dB
Standard up to 38 dB
|
| Key figures | Thermal insulation Uf in W/m²K: from 1,4 to 1,9
Sound insulation Rᵥᵥ,ₚ in dB: from 37,0 to 49,0
Standard face width in mm: 66,5
Construction depth in mm: 75,0
Powder: all Variations
Eloxal: all Variations
Wet coating: all Variations
Stainless steel look: all Variations
Airtightness: 4
Driving rain proofness: 1350
Resistance against wind load: C5/B5
Shockproof: 5
Continuous operation: 3
Corrosion protection class: 4
Operation power: 2
Mechanic strength: 4
|
