| System | Windows
Window door
Ventilation systeme
|
| Material | Alumínium |
| Energy | Thermally insulated (1,3 ≤ Uf ≤ 2,0) |
| Types | Combined pivoting hopper window
Toplights
Fixed glazing
Double vent window
PASK-window door
Renovation window
Supply air
|
| Security | Burglar resistant RC2
Burglar resistant RC3
Protection class SK1
Protection class SK2
Protection class SK3
Protection class SK4
Flue
Supply air elements/slipstream
Avalanche protection
|
| Features | Schüco TipTronic
Motorisable
Schüco WindowControlSystem WCS
Controllable
Comfort control
Radio system
Decentralized ventilation
Raised sound insulation
Fall protection
|
| Control | Manuell switchable
Electric switchable
VOC control
CO2 control
Wet control
Wind control
Approximation control
Switch rail control
Magnetic switch control
|
| Design | Standard
Block system
Multi Countour
|
| Surface | Alu crude (refinementable) |
| Sound insulation | increased sound insulation 38 - 45 dB
increased sound insulation more than 45 dB
Standard up to 38 dB
|
| Key figures | Thermal insulation Uf in W/m²K: from 1,5 to 2,3
Sound insulation Rᵥᵥ,ₚ in dB: from 35,0 to 48,0
Burglar resistance RC: from RC1 to RC3
Standard face width in mm: 67,0
Construction depth in mm: 70,0
Powder: all Variations
Eloxal: all Variations
Wet coating: all Variations
Stainless steel look: all Variations
Airtightness: 4
Driving rain proofness: 1050
Resistance against wind load: C5/B6
Corrosion protection class: 4
Operation power: 2
Mechanic strength: 4
Avalanche protection class: LS15
|
