| System | Windows
Window door
Ventilation systeme
|
| Material | Alumínium |
| Energy | Passiv house suitable (0,8 ≤ Uf ≤ 1,0) |
| Types | Turn windows
Combined pivoting hopper window
Toplights
Fixed glazing
Double vent window
Composite window
Supply air
|
| Security | Burglar resistant RC2
Burglar resistant RC3
Supply air elements/slipstream
|
| Features | Schüco TipTronic
Motorisable
Schüco WindowControlSystem WCS
Controllable
Comfort control
Radio system
Decentralized ventilation
Raised sound insulation
Fall protection
|
| Control | Manuell switchable
Electric switchable
VOC control
CO2 control
Wet control
Wind control
Approximation control
Switch rail control
Magnetic switch control
|
| Design | Standard
Block system
Multi Countour
Alliance
|
| Surface | Alu crude (refinementable) |
| Sound insulation | increased sound insulation 38 - 45 dB
increased sound insulation more than 45 dB
Standard up to 38 dB
|
| Key figures | Thermal insulation Uf in W/m²K from: 0,8
Sound insulation Rᵥᵥ,ₚ in dB: from 45,0 to 53,0
Burglar resistance RC: from RC1 to RC3
Standard face width in mm: 127,0
Construction depth in mm: 120,0
Powder: all Variations
Eloxal: all Variations
Wet coating: all Variations
Stainless steel look: all Variations
Airtightness: 4
Driving rain proofness: 900
Resistance against wind load: C5/B5
Corrosion protection class: 4
Operation power: 1
Mechanic strength: 4
|
